Delta Electronics ASDA-B2 series User Manual

Chapter 3 Connections and Wiring ASDA-B2
3-36 Revision September 2013
3.3.4 User-defined DI and DO signals
If the default DI and DO signals could not be able to fulfill users’ requirements, there
are still user-defined DI and DO signals. The setting method is easy and they are all
defined via parameters. The user-defined DI and DO signals are defined via
parameters P2-10 to P2-17 P2-36 and P2-18 to P2-22 and P-37. Please refer to the
following Table 3.H for the settings.
Table 3.H User-defined DI and DO signals
Signal Name Pin No. Parameter Signal Name Pin No. Parameter
DI
DI1-
CN1-9
P2-10
DO
DO1+ CN1-7
P2-18
DI2-
CN1-10
P2-11 DO1- CN1-6
DI3-
CN1-34
P2-12 DO2+ CN1-5
P2-19
DI4-
CN1-8
P2-13 DO2- CN1-4
DI5-
CN1-33
P2-14 DO3+ CN1-3
P2-20
DI6-
CN1-32
P2-15 DO3- CN1-2
DI7-
CN1-31
P2-16 DO4+ CN1-1
P2-21
DI8-
CN1-30
P2-17 DO4- CN1-26
DI9 CN1-12 P2-36 DO5+ CN1-28
P2-22
DO5- CN1-27
DO6+ CN1-16
P2-37
DO6- CN1-15
