3. Exterior Look of DCS controller and
Descriptions of Connectors
3.1 Exterior look and dimension
175.2 mm
Figure 3-1 Exterior look of DCS Controller
175.2 mm
300.8 mm
70 mm
159.3 mm
50.3 mm
50.3 mm
