1. PRODUCT DESCRIPTION
1.3 Motion range
When SCARA robots line up, the maximum turning radius for first arm is 400 mm and the range of
rotation movement is ±130°; when first arm reaches its limit, second arm can move for other 100°
to reach its limit. The maximum turning radius for second arm is 200 mm and the range of rotation
movement is ±146.6°. The detailed motion range of SCARA is as shown in Figure 1-3.
First Arm
Figure 1-3 SCARA Motion range

Delta DCS Specifications

General

Controller Type	Distributed Control System (DCS)
Manufacturer	Delta Electronics
Programming Language	IEC 61131-3 (LD, FBD, SFC, ST, IL)
Communication Protocols	OPC UA
Power Supply	24 VDC
Humidity Range	non-condensing
I/O Modules	Analog, Digital
Redundancy	Optional
Certifications	CE, UL
