4. Hardware components
5.1 Connector components
Table 5-1 DCS Accessories List
ITEM
NAME
NOTES
Q’TY
1
MOTOR POWER Connector J1&J3
3050248246
1
2
MOTOR POWER Connector J2&J4
3050248646
3
MAIN POWER INPUT Connector
3051611346
1
4
DC 24V INPUT Connector
3051627346
1
5
Motor brake release Connector
3051618746
1
