Delta RPI Series User Manual

D1 D2 D3
P
D1 6.5 〜 2030.8 〜 44.7 1 〜 7.5
D2 11 〜 1726.8 〜 35.4 1〜6
D3 13 〜 1421.9 〜 27.6 1 〜 3.5
1225 3.5D3（38 ㎜ ²）
Settle the AC Plug according to the process from P.25 and P.26. This AC Plug can
accommodate either positive or negative phase of wire. In other words, the sequence
of L1, L2, L3 can be adjusted arbitrarily.
According to the diameter of the cable, choose the combination of rubber ring(D1 or
D1+D2 or D1+D2+D3) then tighten by the torque suggested by below table.
Figure 4-5 : Combination of Rubber ring
Table 4-4 : Packing and tightening torque
Seal
Outer jacket diameter
(mm)
Tightening torque
(N・m)
Gap P
(mm)
24
Wiring
