Denon AVR-3808 User Manual


Getting Started Setup Playback Remote Control Multi-Zone Information Troubleshooting
ENGLISH
USB Port
• In the initial status, USB memory devices can be used by connecting them to the USB port on the front panel.
• To change the port to be used, see “USB Select” on page 40.
• For instructions on playing the files on a USB memory device, see page 56.
NOTE
• Set to the USB port you want to use.
• The AVR-3808 is equipped with two USB ports, one each on the front and rear panels. It is not possible to use the set with USB memory
devices connected to both the ports at the same time. Select the USB port you want to use at the GUI menu “Source Select” – “NET/USB” –
“Playback Mode” – “USB Select”.
n Front panel n Rear panel
USB memory device USB memory device
Connections
• Do not use the extension cable for connecting the USB memory device to the AVR-3808’s USB port.
Use of the extension cable may cause harmful interference.
1.AVR3808E2_ENG_104.indd 22 2007/10/25 15:16:36

Denon AVR-3808 Specifications

General

Type	AV Receiver
Channels	7.1
Power Output per Channel	130 W (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
HDMI Inputs	4
HDMI Outputs	2
Network Connectivity	Ethernet
THD	0.05%
Component Video Inputs	3
Component Video Outputs	1
Digital Audio Inputs (Coaxial)	2
Preamp Outputs	7.1
Weight	15.5 kg
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity/Impedance	200 mV / 47 kOhms
Signal-to-Noise Ratio	100 dB
HDMI Version	1.3a
Supported Video Formats	1080p
Dolby Technologies	Dolby Digital, Dolby Digital EX, Dolby TrueHD, Dolby Pro Logic IIx
DTS Technologies	DTS-HD Master Audio
Multi-room Zones	3
Video Inputs/Outputs	Composite
Audio Inputs/Outputs	Analog, Digital Optical, Digital Coaxial
