Denon AVR-3808 User Manual


Getting Started Connections Setup Remote Control Multi-Zone Information Troubleshooting
ENGLISH
INPUT MODE
uipENTER
About the button names in these explanations
< > : Buttons on the main unit
[ ] : Buttons on the remote control unit
Button name only:
Buttons on the main unit and remote control unit
INPUT MODE
ENTER
uip
(Main remote control unit)
(Sub remote control unit)
[REPEAT]
[RANDOM]
[USB]
Playing Files Stored on USB Memory
Devices
Only USB memory devices conforming to mass storage
class and MTP (Media Transfer Protocol) standards can be
played on the AVR-3808.
Basic Operation
1
Make the necessary preparations.
• Set the USB port to be used.
1
• Set the USB port to be used.
: “Source Select” – “NET/USB” –
“Playback Mode” – “USB Select” (vpage 40)
• Connect the USB memory device to the set USB port.
2
Use ui to select “USB”, then press ENTER or p.
3
Use ui to select the search item or folder, then press
ENTER or p.
4
Use ui to select the  le, then press ENTER or p.
Playback starts once buffering reaches “100%”.
By default, the front panel’s USB port will be used.
Playing repeatedly
Press [REPEAT] on the sub remote control unit.
[Selectable items] All
One OFF
: “Source Select” – “NET/USB” –
“Playback Mode” – “Repeat” (vpage 40)
Playing in random order
Press [RANDOM] on the sub remote control unit.
[Selectable items] ON OFF
: “Source Select” – “NET/USB” –
“Playback Mode” – “Random” (vpage 40)
• If the USB memory device is divided into multiple partitions, only the
top partition can be selected.
• The AVR-3808 is compatible with MP3 fi les conforming to “MPEG-1
Audio Layer-3” standards.
• If [USB] on the sub remote control unit is pressed when the USB
memory device or folder is selected, all the tracks on the USB
memory device or in the folder are played.
NOTE
• The AVR-3808 is equipped with two USB ports, one each on the
front and rear panels. It is not possible to use the set with USB
memory devices connected to both the ports at the same time.
Select the USB port you want to use at the “Source Select” – “NET/
USB” – “Playback Mode” – “USB Select” menu.
• DENON will accept no responsibility whatsoever for any loss or
damage to data on USB memory devices when using the USB
memory device connected to the AVR-3808.
• USB memory devices will not work via a USB hub.
• DENON does not guarantee that all USB memory devices will operate
or receive power. When using a USB connection type portable hard
disk of the type for which power can be supplied by connecting an
AC adapter, we recommend using the AC adapter.
• It is not possible to connect and use a computer via the AVR-3808’s
USB port using a USB cable.
• The AVR-3808 is not compatible with the iPod shuffl e.
Selecting tracks
During playback, either press u (previous track) or i (next track).
Surround mode
Surround mode
Playback
1.AVR3808E2_ENG_104.indd 60 2007/10/25 15:17:59

Denon AVR-3808 Specifications

General

Type	AV Receiver
Channels	7.1
Power Output per Channel	130 W (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
HDMI Inputs	4
HDMI Outputs	2
Network Connectivity	Ethernet
THD	0.05%
Component Video Inputs	3
Component Video Outputs	1
Digital Audio Inputs (Coaxial)	2
Preamp Outputs	7.1
Weight	15.5 kg
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity/Impedance	200 mV / 47 kOhms
Signal-to-Noise Ratio	100 dB
HDMI Version	1.3a
Supported Video Formats	1080p
Dolby Technologies	Dolby Digital, Dolby Digital EX, Dolby TrueHD, Dolby Pro Logic IIx
DTS Technologies	DTS-HD Master Audio
Multi-room Zones	3
Video Inputs/Outputs	Composite
Audio Inputs/Outputs	Analog, Digital Optical, Digital Coaxial
