Information
Power
Select Source
Volume Level
Select Source
Name
Surround Mode
Input Mode
Assign
Room EQ
Video Select
Src Level
Rec Select
Night Mode
RESTORER
etc.
Status
Shows information about current settings.
F Menu tree F
Information
Status
a MAIN ZONE
s ZONE2/3
a
MAIN ZONE
Shows information about settings for main zone.
The items displayed differ according to the input source.
s
ZONE2/3
Shows information about settings for multi-zone.
[Items to be checked]
[Items to be checked]
Audio Input Signal
Shows information about audio input
signals.
F Menu tree F
Information
Audio Input Signal
Surround Mode
: The currently set surround mode is displayed.
Signal
: The input signal type is displayed.
fs
: The input signal’s sampling frequency is
displayed.
Format
: The number of channels in the input signal (front,
surround, LFE) is displayed.
Offset
: The dialogue normalization correction value is
displayed.
Flag
: “MATRIX” is displayed if the input signal has
undergone matrix processing, “DISCRETE” if the
input signal has undergone discrete processing.
Dialogue normalization function
This is automatically activated when playing Dolby Digital sources.
This function automatically corrects the standard signal level for
individual program sources.
The correction value can be checked using the STATUS button on
the main unit.
The fi gure is the correction value when the standard level is
corrected.
[Items to be checked]
–6
~
0
~
+6
0
~
+12
Picture Adjust
Adjust the picture quality.
F Menu tree F
Parameter
Picture Adjust
a Contrast
s Brightness
d Chroma Level
f Hue
[Variable range]
[Variable range]
[Variable range]
[Variable range]
–6
~
0
~
+6
–6
~
0
~
+6
a
Contrast
Adjust picture contrast.
• Adjusting the “Contrast”, “Brightness”, “Chroma Level” and “Hue”
settings does not affect the HDMI input signal.
• “Hue” can be adjusted for composite video and S-Video signals.
• The adjustment values are stored for the individual input sources.
s
Brightness
Adjust picture brightness.
d
Chroma Level
Adjust picture chroma level (saturation).
f
Hue
Adjust color hue.
