Getting Started Connections Playback Remote Control Multi-Zone Information Troubleshooting
ENGLISH
NON MTRX
MTRX ON
PL
II
x CINEMA
z1
PL
II
x MUSIC
z2
ES MTRX
z3
ES DSCRT
z4
DSCRT ON
OFF
z1: This can be selected when “Surround Back” is set to “2spkrs”
at the GUI menu “Manual Setup” – “Speaker Setup” – “Speaker
Configuration” setting (vpage 28).
z2: This can be selected when “Surround Back” is set to “2spkrs”
or “1spkr” at the GUI menu “Manual Setup” – “Speaker Setup”
–“Speaker Configuration” setting.
z3: This can be selected when playing DTS sources.
z4: This can be selected when playing DTS sources including a
discrete 6.1-channel signal identification signal.
ON
OFF
[Selectable items]
AFDM
Auto-select surround mode by source.
This function only works for software containing a special identification
signal.
If the software being played is recorded in Dolby Digital EX or DTS-ES,
it is played in 6.1-channels. If not, it is played in 5.1-channels.
Example : Playing Dolby Digital software (with EX flag)
• When “AFDM” is set to “ON”, the surround mode is automatically
set to the DOLBY D + PLgx C mode.
• To play in the DOLBY DIGITAL EX mode, set “AFDM” to “OFF” and
“SB CH Out” to “MTRX ON”.
Some Dolby Digital EX sources do not include EX flags. If the playback
mode does not switch automatically even when “AFDM” is set to
“ON”, set “SB CH Out” to “MTRX ON” or “PLgx CINEMA”.
SB CH Out (for Multi-channel sources)
Select playback mode for surround back channels.
[Selectable items]
ON
OFF
[Selectable items]
SB CH Out (for 2-channel sources)
Determine whether to use surround back speakers.
–6dB ~ +6dB
–6dB ~ +6dB
Subwoofer Att.
Attenuate subwoofer level when using EXT. IN mode.
Set this to “ON” if the subwoofer channel level seems too high when
playing Super Audio CD.
Subwoofer
Turn subwoofer output on and off.
Default
Resets the settings to the default values.
Tone Defeat
Turn tone adjustments off.
The tone cannot be adjusted when in the DIRECT mode.
Bass
Adjust low frequency range (bass).
Treble
Adjust high frequency range (treble).
“Bass” and “Treble” can be set when “Tone Defeat” is set to “OFF”.
ON
OFF[Selectable items]
ON
OFF
[Selectable items]
ON
OFF[Selectable items]
[Variable range]
[Variable range]
s
Tone
Adjust the tonal quality of the sound.
1
~
10
~
15
Small
Medium small
Medium
Medium large
Large
Effect Level
Adjust effect signal level.
Room Size
Determine size of acoustic environment.
[Variable range]
[Selectable items]
Set to a lower level if the positioning and sense of phase of the
surround signals seems unnatural.
NOTE
“Room Size” does not indicate the size of the room in which sources
are played.
Setup
To Next Page
