ENGLISH
HDMI
(High-Definition Multimedia Interface)
HDMI is a digital interface standard for next generation TVs based
on DVI (Digital Visual Interface) standards and optimized for use in
consumer equipment.
Non-compressed digital video and multi-channel audio signals are
transmitted with a single connection.
HDMI is also compatible with HDCP (High-bandwidth Digital Contents
Protection), a technology for protecting copyrights that encrypts digital
video signals in the same was as with DVI.
“HDMI”, “HDMI logo” and “High-Definition Multimedia Interface”
are trademarks or registered trademarks of HDMI Licensing
LLC.
Deep Color
Eliminates on-screen color banding, for smooth tonal transitions and
subtle gradations between colors.
Enables increased contrast ratio.
Can represent many times more shades of gray between black and
white.
At 30-bit pixel depth, a four times improvement would be the minimum,
and the typical improvement would be eight times or more.
xvYCC
Next-generation “xvYCC” color space supports 1.8 times as many
colors as existing HDTV signals.
Lets HDTVs display colors more accurately.
Enables displays with natural, vivid colors.
Lip Sync
Because consumer electronics devices are using increasingly
complex digital signal processing to enhance the clarity and detail of
the content, synchronization of video and audio in user devices has
become a greater challenge and could potentially require complex end-
user adjustments. HDMI 1.3 incorporates an automatic video/audio
synching capability that allows devices to perform this synchronization
automatically with total accuracy.
Surround Mode
Signals and adjustability in the different modes
Channel output Parameter (default values are shown in parentheses)
Front L/R Center
Surround
L/R
Surround
Back L/R
Subwoofer
D. COMP
z
1
LFE
z
2
AFDM
z
1
SB CH Out Cinema EQ.
PURE DIRECT, DIRECT
S A A A D S (OFF) S ( 0 dB) A A A
DSD DIRECT
S A A A A A A A A A
DSD MULTI DIRECT
S D D D D A S ( 0 dB) A S A
MULTI CH DIRECT
S D D D D A S ( 0 dB) S (ON) S A
STEREO
S A A A D S (OFF) S ( 0 dB) A A A
EXT. IN
S D D D D A A A A A
MULTI CH IN
S D D D D A S ( 0 dB) S (ON) S A
WIDE SCREEN
S D D D D S (OFF) S ( 0 dB) A S S (OFF)
DOLBY PRO LOGIC gx S D D D D S (OFF) A A S S (NOTE1)
DOLBY PRO LOGIC g S D D A D S (OFF) A A S S (NOTE2)
DTS NEO:6
S D D D D S (OFF) A A S S (NOTE1)
DOLBY DIGITAL
S D D D D S (OFF) S ( 0 dB) S (ON) S S (OFF)
DTS SURROUND
S D D D D S (OFF) S ( 0 dB) S (ON) S S (OFF)
7CH STEREO
S D D D D S (OFF) S ( 0 dB) A S A
SUPER STADIUM
S D D D D S (OFF) S ( 0 dB) A S A
ROCK ARENA
S D D D D S (OFF) S ( 0 dB) A S A
JAZZ CLUB
S D D D D S (OFF) S ( 0 dB) A S A
CLASSIC CONCERT
S D D D D S (OFF) S ( 0 dB) A S A
MONO MOVIE
S D D D D S (OFF) S ( 0 dB) A S A
VIDEO GAME
S D D D D S (OFF) S ( 0 dB) A S A
MATRIX
S D D D D S (OFF) S ( 0 dB) A S A
VIRTURL
S A A A D S (OFF) S ( 0 dB) A A A
S : Enable
A : Unable
NOTE1 : This parameter is availabe when the GUI menu “Parameter”
– “Audio” – “Surround Parameters” – “Mode” is set to
“Cinema” (vpage 42).
NOTE2 : This parameter is availabe when the GUI menu “Parameter”
– “Audio” – “Surround Parameters” – “Mode” is set to
“Cinema” or “Pro Logic” (vpage 42).
NOTE:
z
1 : When playing Dolby Digital and DTS signals.
z
2 : When playing Dolby Digital, DTS, DVD-Audio and Super
Audio CD.
S : Signal / Adjustable
A : No signal / Not adjustable
D : Turned on or off by speaker configuration setting
Surround Modes and Parameters
Information
