Shunt Resistor Accuracy
0.05 %; TCR: 10 ppm/K (others on request)
Input Short, Sensor Offset Adjust
Software-selectable
Additional Specifications
Input connectors
Terminal block, DSUB-37
TEDS support
Available for Terminal block
Power supply
9 - 48 V DC
Power Consumption
Typ. 2.7 W, Max. 5.1 W (120 Ω @ 5 V load)
Weight
340 g
Slice Dimensions
128.4 x 118.4 x 30.14 mm
1) Ratiometric method
2) Range is HW range in bridge mode in unit V/V and Excitation is currently used excitation in unit V
4.3.2.1.1. IOLITEr-8xSTGS: Bridge Accuracy Specifications
HW Range
Used Excitation
Accuracy
1000 mV/V
1 V
±0.21 % of reading ±210 µV/V
100 mV/V
1 V
±0.2 % of reading ±30 µV/V
20 mV/V
1 V
±0.15 % of reading ±14 µV/V
500 mV/V
2 V
±0.11 % of reading ±105 µV/V
50 mV/V
2 V
±0.097 % of reading ±15 µV/V
10 mV/V
2 V
±0.07 % of reading ±7 µV/V
200 mV/V
5 V
±0.07 % of reading ±42 µV/V
20 mV/V
5 V
±0.048 % of reading ±6 µV/V
4 mV/V
5 V
±0.036 % of reading ±2.8 µV/V
