IOLITE®
TECHNICAL REFERENCE MANUAL
4.4.1.2. IOLITEi-8xTH: Miniature Thermocouple Connector
IOLITEi-8xTH module has 8 miniature thermocouple-connectors for temperature measurement.
IOLITEir-8xTH front
4.4.1.2.1. IOLITEi-8xTH: Miniature Thermocouple Connector: Pinout
TH connector: pin-out (Mini TC female)
Pin
Name
Description
1
In+
Input+
2
In-
Input-
IOLITE® V22-2 125 / 193
