IOLITE®
TECHNICAL REFERENCE MANUAL
3.1.2. Input Slots and Amplifiers
IOLITE-R12
IOLITE-R8
IOLITE-R8r
IOLITE chassis can be configured with up to 12
slots, each featuring high-quality input amplifiers.
Currently, the following amplifiers are available:
6xSTG : universal analogue and strain gauge
amplifiers. Compatible with Dewesoft smart
interface DSI adapters
8xSTGS: A dedicated module for strain
measurement with low drift and high
stability
8xLV : Isolated 8-channel low voltage module
16xLV: 16-channel low voltage module.
8xLA: Isolated 8-channel low current
module.
8xTH, 8xTH-HS : Isolated thermocouple
amplifier
8xRTD, 8xRTD-HS: isolated amplifiers for
measurements with a resistance
temperature detector
32xDI : 32 channel digital input
32xDO : 32 channel digital output with
watchdog functionality
8xDI 4xDO : 8 digital input and 4 digital
output channels.
4xCNT : 4 channel digital counter input with
SuperCounter® technology.
16xAO : 16 analogue out channels
Full technical specifications in 4. Module Overview
IOLITE® V22-2 27 / 193
