DEWESOFT IOLITE V22-2 User Manual

IOLITE®
TECHNICAL REFERENCE MANUAL
4.7.1.1. IOLITEr-32xDI: Specifications
Digital Input
Isolated Input Channels
32
Input low level
-1 V ~ +1 V
Input high level
-48 V ~ -3 V, +3 V ~ +48 V
Input high current @ 5 V
UIN < 1 mA
Input high current @ 30 V
UIN < 1 mA
Sampling rate
Simultaneous 20 kS/s
Overvoltage protection
100 V continuous (250 Vpeak)
Isolation voltage peak
1000 V Isolated common GND, groups of 8 ch
Additional Specifications
Input connectors
Terminal block, 2 pole, 4 x 9 pole
OMNIMATE SL 2.50 / BLF 2.50/180
Power supply
9 - 48 V DC
Power out
max. 2 A (unprotected)
Power consumption
Typ. 1.2 W, Max. 1.9 W
Weight
220 g
Slice Dimensions
128.4 x 115.4 x 30.1 mm
IOLITE® V22-2 162 / 193
