Important
The common pin is not shared through all the 32 channels, but by groups of 8 channels. Isolation
concept is shown in case of 32xDI .
Hint
Check how to use DO as a switch on this LINK .
4.7.3. IOLITE-8xDI-4xDO
IOLITE 8xDI-4xDO module has 8 digital inputs and 4 digital outputs. Digital IN and OUT banks are
isolated from each other and can be powered by separate external power supplies. Module comes in
rack version and offers watchdog function and is a perfect choice for more demanding industrial
applications such as valve control, with a maximum sink current 0.5 A and maximum switching voltage
50 V.
IOLITEr-8xDI-4xDO module
