DEWESOFT IOLITE V22-2 User Manual

IOLITE®
TECHNICAL REFERENCE MANUAL
5. ECAT Accessories
5.1. IOLITE Power injector
IOLITE Power Injector is a passive PoE power injector. It merges a 12-48V DC power source and the
EtherCAT communication into a single CAT6 cable. The IOLITE single channel devices need the IOLITE
Power injector as the first device in the chain.
IOLITE Power injector
5.1.1. General specifications
General specifications
Digital interface
EtherCAT
EtherCAT connector
RJ45
Power connectors
Wire terminal, 2mm jack
Erath connectors
Wire terminal
Wire terminal connector type
MC 1,5 / 3-STF-3.81
Power consumption
< 500 mW
Supply Voltage
12 V - 48 V
Operating temperature
-20 …. 60 degC
IP rating
IP20
Weight
105 g
Housing material
Aluminium
IOLITE® V22-2 181 / 193
