IOLITE®

TECHNICAL REFERENCE MANUAL

List of required cables:

Function

Dewesoft order code

Power supply

Sirius: PS-120-L1B2f (default)

Sirius to IOLITE: L1B2m-L1B2f-0.2m,

L1B2m-L1B2f-0.4m, L1B2M-L1B2F-3m

EtherCAT

IOLITE to PC: L1T8f-RJ45-1M (default),

L1T8f-RJ45-3M, L1T8f-RJ45-5M

USB

CABLE-USBAmini-USBBS-1.8m (default),

CABLE-USBAmini-USBBS-1m

Synchronization

L00B4m-L00B4m-0.2m (default),

L00B4m-L00B4m-0.5m, L00B4m-L00B4m-3m

3.3.2.7. IOLITE-R8: Boxed Chassis: Connection of IOLITE multi and single channel device

Connect power supply cable to IOLITE-R8 (PS-120W-L1B2f).Then connect L1T8f-RJ45-1M cable (LEMO

side) to IN connector of BUS 1 on IOLITE-R8 back panel.

Use the L1T8m-RJ-45 cable to connect the IOLITE - single channel device. An additional power cable is

not needed, as the device can power over Ethernet cable.

Use a RJ-45 - RJ-45 cable to connect the IOLITE - multichannel device. An additional Power supply is

needed for the device with the cable.

IOLITE® V22-2 52 / 193
