4.5.1.2. IOLITEi-1xACC: BNC Connector
4.5.1.2.1. IOLITEi-1xACC: BNC Connector: Pinout
ACC connector: pin-out (BNC)
Pin
Name
Description
1
IN+
Input +
2
GND
Ground
4.5.1.2.2. IOLITEi-1xACC: BNC Connector: Wiring diagram
Voltage
