IOLITE®
TECHNICAL REFERENCE MANUAL
Connection of IOLITE-R8r and two different IOLITE devices
Function
Dewesoft order code
Power supply
IOLITE-R8r: PS-120-L1B2f (default)
IOLITE-multichannel:
EtherNET
IOLITE-R8r to IOLITE single channel: RJ-45 - RJ-45
IOLITE single channel to IOLITE multi channel: RJ-45 - RJ-45
IOLITE® V22-2 64 / 193
