Overview for single channel devices
1xACC
1xSTG
4xDI
4xDO
1xAO
Input / Output
types
Input: Voltage, IEPE
Input: Voltage, Strain
Input: Digital
Output: Digital
Output: Voltage
Number of
channels per
module
1
1
4
4
1
Connector
BNC
DB9
DSUB15HD male
DSUB15HD female
BNC
Data rate per
channel
40 kS/s
40 kS/s
20 kS/s
Resolution
24-bit
24-bit
Digital
Digital
18-bit
Bandwidth
0.49 fs
0.49 fs
X
X
X
Alias-free
Bandwidth
0.453 fs
0.453 fs
X
X
X
Alias Rejection
-100 dB (all sample
rates)
-100 dB (all sample
rates)
X
X
X
Delay Through ADC
37 / fs
37 / fs
X
X
X
Oversampling
32
32
X
X
X
Voltage ranges
±10 V, ±5 V, ±1 V, ±200
mV
±50 V, ±10 V, ±1 V,
±100 mV
Digital (Low: < 1 V,
High: > 2 V)
X
±10 V
Isolation
125 Vrms Isolation
CH, GND
125 Vrms Isolation
CH, GND
CH-CH, GND-GND
CH-GND
X
Power supply
12-48V
12-48V
12-48V
12-48V
12-48V
Power
consumption
2W
2.5W
2.5W
2.5W
2W
Operating
temperature
-20..60 °C
-20..60 °C
-20..60 °C
-20..60 °C
-20..60 °C
Storage
temperature
-20..60 °C
-20..60 °C
-20..60 °C
-20..60 °C
-20..60 °C
Dimensions
82 x 62 x 28 mm
71 x 62 x 28 mm
71 x 62 x 28 mm
71 x 62 x 28 mm
82 x 62 x 28 mm
Weight
130 g
130 g
130 g
130 g
130 g
IOLITE® V22-2 76 / 193
