2.4 Orin NX and Orin Nano Modules Overview
Orin Nano Feature Description
Feature
s
Jetson Orin Nano 4GB/8G
B
AI Performance 20 TOPS (Sparse) |10 TOPS (Dense) / 40 TOPS (Sparse) |20 TOPS (Dense)
GPU
512 core NVIDIA Ampere GPU with 16 Tensor Cores /
1024 core NVIDIA Ampere GPU with 32 Tensor Cores
CPU 6core NVIDIA Arm® Cortex A78AE v8.2 64-bit CPU, 1.5 GHz 1.5MB L2 + 4MB L3
VIDEO
1x 8K @ 30 Encode (HEVC)
1x 4K @ 60 Decode (HEVC)
MEMORY
4GB 64bit LPDDR5 @2133 MHZ, 34 GB/s /
8GB 128bit LPDDR5 @2133 MHZ, 68 GB/s
CAMERA 8 lanes (2x4 or 4x2) MIPI CSI-2 D-PHY 1.2 (2.5 Gb/s per pair)
CONNECTIVITY 1 Gigabit Ethernet, 3 x1 + 1 x4 PCIe lanes
DISPLAY HDMI 2.1 and eDP 1.4
USB 3x USB 3.2, 3x USB 2.0
OTHERS GPIO, I2C, I2S, SPI, UART
POWER 5W to 10W / 7W to 15W
Orin NX Feature Description
Feature
s
Jetson Orin NX 8GB/16G
B
AI Performance 70 INT8 Sparse TOPs /100 INT8 Sparse TOPS
GPU 1024 core NVIDIA Ampere GPU with 32 Tensor Cores
CPU 6-core NVIDIA A78 CPU /8-core NVIDIA A78 CPU
VIDEO
1x 8K @ 30 Encode (HEVC)
1x 4K @ 60 Decode (HEVC)
MEMORY
8GB 128bit LPDDR5 @2133 MHZ, 102GB/s /
16 GB 128-bit LPDDR5, 3200MHz 102GB/s
CAMERA 8 lanes (2x4 or 4x2) MIPI CSI-2 D-PHY 1.2 (2.5 Gb/s per pair)
CONNECTIVITY 1 Gigabit Ethernet, 3 x1 + 1 x4 PCIe lanes
DISPLAY HDMI 2.1 and eDP 1.4
USB 3x USB 3.2, 3x USB 2.0
OTHERS GPIO, I2C, I2S, SPI, UART
POWER 10W to 20W / 10W to 25W
