Jackson User Manual rev 2.2 www.diamondsystems.com Page 14
3.14 Utility
Some of the housekeeping & additional interfaces signals like Power button, Debug TTL UART, Reset, I2C, SPI
and Force recovery signals are available through a 2x10 utility header.
3.15 LED Indicators
The board provides the following LED indicators. All LEDs are located near to the board edge or their respective
features. All LEDs are labeled in silkscreen with their function.
PWIN Green LED for Power IN
PWGD Green LED for Power Good indication.
PMOD Green LED for Boot indication.
USER Green LED for user /boot indication
