Jackson User Manual rev 2.2 www.diamondsystems.com Page 21
7 CONNECTOR SPECIFICATIONS
7.1 Jetson Module I/O Connector (J11)
Jetson Orin
Module Function
Pin# Pin# Jetson Orin
Module Function
GND
1 2
GND
CSI1_D0_N
3 4
CSI0_D0_N
CSI1_D0_P
5 6
CSI0_D0_P
GND
7 8
GND
CSI1_CLK_N
9 10
CSI0_CLK_N
CSI1_CLK_P
11 12
CSI0_CLK_P
GND
13 14
GND
CSI1_D1_N
15 16
CSI0_D1_N
CSI1_D1_P
17 18
CSI0_D1_P
GND
19 20
GND
CSI3_D0_N
21 22
CSI2_D0_N
CSI3_D0_P
23 24
CSI2_D0_P
GND
25 26
GND
CSI3_CLK_N
27 28
CSI2_CLK_N
CSI3_CLK_P
29 30
CSI2_CLK_P
GND
31 32
GND
CSI3_D1_N
33 34
CSI2_D1_N
CSI3_D1_P
35 36
CSI2_D1_P
GND
37 38
GND
USBSS1_RX_N
39 40
PCIE2_RX0_N
USBSS1_RX_P
41 42
PCIE2_RX0_P
GND
43 44
GND
USBSS1_TX_N
45 46
PCIE2_TX0_N
USBSS1_TX_P
47 48
PCIE2_TX0_P
GND
49 50
GND
USBSS2_RX_N
51 52
PCIE2_CLK_N
USBSS2_RX_P
53 54
PCIE2_CLK_P
GND
55 56
GND
USBSS2_TX_N
57 58
PCIE2_RX1_N
(PCIE3_RX0_N)
USBSS2_TX_P
59 60
PCIE2_RX1_P
(PCIE3_TX0_P)
GND
61 62
GND
DP1_TXD0_N
63 64
PCIE2_TX1_N
(PCIE3_TX0_N)
DP1_TXD0_P
65 66
PCIE2_TX1_P
(PCIE3_TX0_P)
GND
67 68
GND
DP1_TXD1_N
69 70
RSVD
DP1_TXD1_P
71 72
RSVD
GND
73 74
GND
DP1_TXD2_N
75 76
RSVD
DP1_TXD2_P
77 78
RSVD
GND
79 80
GND
DP1_TXD3_N
81 82
RSVD
DP1_TXD3_P
83 84
RSVD
GND
85 86
GND
GPIO00
87 88
RSVD
SPI0_MOSI
89 90
RSVD
SPI0_SCK
91 92
RSVD
SPI0_MISO
93 94
HDMI_CEC
SPI0_CS0*
95 96
DP1_HPD
SPI0_CS1*
97 98
DP1_AUX_N
