2.2 Jackson Ordering Guide
The table below lists the current and planned part numbers in the Jackson product family.
JAX-BB01 Jackson carrier board for NVIDIA Jetson Orin Nano & Orin NX
JAX-BB02
Jackson carrier board for NVIDIA Jetson Orin Nano & Orin NX, low-cost variant (without
one Ethernet interface and Expansion connector)
9242652
Jackson carrier board for NVIDIA Jetson Orin Nano & Orin NX, custom variant with 1 UART
and 1 RS232 port
JAX-ASY-ONA4 Jackson BB01 carrier board with Orin Nano 4GB installed and programmed, with fan sink
JAX-ASY-ONA8 Jackson carrier board with Orin Nano 8GB installed and programmed, with fan sink
JAX-ASY-ONA4-2 Jackson BB02 carrier board with Orin Nano 4GB installed and programmed, with fan sink
JAX-ASY-ONX8 Jackson carrier board with Orin NX 8GB installed and programmed, with fan sink
JAX-ASY-ONX16 Jackson carrier board with Orin NX 16GB installed and programmed, with fan sink
The below table lists the components included in the Jackson assemblies:
DSC Part Numbe
r
Carrier
Board Jetson Module NVMe SSD
Thermal
Solution OS
JAX-ASY-ONA4 JAX-BB01
Orin Nano 4GB
Module
M.2 2280 NVMe x4
128GB 3D TLC
Heat Sink
with Fan
OS Image, Linux for
Orin Nano
JAX-ASY-ONA4-2 JAX-BB02
Orin Nano 4GB
Module
M.2 2280 NVMe x4
128GB 3D TLC
Heat Sink
with Fan
OS Image, Linux for
Orin Nano
JAX-ASY-ONA8 JAX-BB01
Orin Nano 8GB
Module
M.2 2280 NVMe x4
128GB 3D TLC
Heat Sink
with Fan
OS Image, Linux for
Orin Nano
JAX-ASY-ONX16 JAX-BB01
Orin NX 16GB
Module
M.2 2280 NVMe x4
128GB 3D TLC
Heat Sink
with Fan
OS Image, Linux for
Orin NX
JAX-ASY-ONX8 JAX-BB01
Orin NX 8GB
Module
M.2 2280 NVMe x4
128GB 3D TLC
Heat Sink
with Fan
OS Image, Linux for
Orin NX
The table below lists the part numbers for supported accessories used with Jackson.
CK-JAX-01 Cable Kit, Jackson Nvidia Jetson Orin Nano / NX Carrier Board
8882280 Nvidia Jetson Orin Nano 4GB Module
8882281 Nvidia Jetson Orin Nano 8GB Module
8882285 Nvidia Jetson Orin NX 8GB Module
8882286 Nvidia Jetson Orin NX 16GB Module
FDM2-2280NT1-128G M.2 2280 NVMe x4 128GB 3D TLC -40/+85C
6882650 Heat Sink, Jackson Carrier for Orin Nano and NX
4810010 Fan, 30x30mm 6.9mmH, 5V 4-Wire JWT A1251H02-4P-HF Connector
ACC-CAM-001 e-con Camera Adapter Board for two e-con cameras
ACC-CAM-002 Allied Vision Camera Adapter Board for two Allied Vision cameras
The table below lists the software support for Jackson product.
8512651 OS Image, Jackson, Linux for Orin Nano 4GB/8GB
8512650 OS Image, Jackson, Linux for Orin NX 8/16GB
