Jackson User Manual rev 2.2 www.diamondsystems.com Page 36
9 CONNECTOR SUMMARY
The following table provides a summary of all I/O connectors on the board.
Function
Manufactur
er
Part no. Description
DSC Mating
Cable
Module connector
TE
Connectivity
2309413-1
DIMM Connectors DDR4 SODIMM 260P 9.2H
STD
NA
Power In CUI Inc. PJ-202BH CONN PWR JACK 2.5X5.5MM SOLDER NA
RTC battery Molex 0533980271 CONN HEADER VERT 2POS 1.25MM
6980529,
4713001
Fan Molex 0533980471 CONN HEADER SMD 4POS 1.25MM NA
GbE Link PP LPJG16470ADNL SINGLE PORT RJ45 CONNECTOR Standard
HDMI Foxconn QJ3119C-WFB1-4F UP RIGHT HDMI CONNECTOR Standard
Serial Ports Molex 0877581016 CONN HEADER VERT 10POS 2MM 6981075
CAN JST
BM04B-GHS-
TBT(LF)(SN)(N)
CONN HEADER SMD 4POS 1.25MM 6981182
Camera Amphenol
G832MB030801322H
R
CONN B2B 80-PIN 0.8MM PITCH NA
Expansion
Connector
Hirose FH55-40S-0.5SH CONN FFC FPC 0.5MM SMD FFC cable
Digital IO Oupiin
0877582016 /
951220-7622-AR
CONN HEADER VERT 20POS, 2X10 2.54MM
CONN HEADER RA 20POS, 2X10 2.54MM
C-20MM-18
M.2 SSD socket Amphenol 10128798-005RLF CONN FEMALE 67POS 0.020 GOLD NA
M.2 PCIe E-Key Amphenol 2199230-4 CONN M.2 FEMALE 67POS 0.020 GOLD NA
Minicard TE
1759547-1
CONN PCI EXP MINI FEMALE 52POS
NA
USB 3.0/ USB2.0 Molex
484060003
USB 3.0 A TYPE, RA, T/H, 9 POS
Standard
USB 3.0/ USB2.0
Amphenol
98414-G06-10LF /
98464-G61-10ULF
CONN HEADER VERT 10POS 2MM
CONN HEADER RA 10POS 2MM
6980603
USB2.0
JST
SM05B-GHS-
TB(LF)(SN)
CONN HEADER SMD 5POS 1.25MM
6980504
Utility Oupiin
0877582016 /
951220-7622-AR
CONN HEADER VERT 20POS, 2X10 2MM
CONN HEADER RA 20POS, 2X10 2MM
C-20MM-18
