2 INTRODUCTION
2.1 Jackson Product Overview
Jackson is an Orin Nano / Orin NX module-based board with rich graphics and camera input capability. This base
board converts the module into a complete embedded system by providing interface circuitry, I/O connectors for
all the major features of the module, camera interface, power supply and additional I/O capabilities.
This Base Board redefines possibility; a combination of performance, power efficiency, integrated deep learning
capabilities and rich I/O remove the barriers to a new generation of low-cost products.
The base board also contains M.2 x4 lane PCIe SSD as storage options along with interfaces like HDMI, USB3.2,
CAN, Serial ports, Utility connector etc.
Jackson Features
Featur
e
Descriptio
n
Connector Typ
e
Power 7V-20V wide input supply
DC barrel jack or
Terminal Block (J2/J3)
RTC 3V power input for RTC functionality 1x2 connector (J28)
Ethernet
1x 10/100/1000Mbps from the Orin NX/ Nano module 1x RJ45 Connector (J25)
*1x 10/100/1000Mbps from the I210 controller 1x RJ45 Connector (J24)
Mass Storage
1 Minicard expansion with x1 PCIe and x1 USB2.0
with SIM connector
PCIe Minicard 52 Position (52-Pin-
Surface Mount, Right Angle) (J18)
1 M.2 M Key (2280 or 2242) (NVMe) expansion slots
(4 lane PCIe Gen 3)
M.2 (Key M) Socket (J20)
1 M.2 E key 2230
67 Position Female M.2 Connector
(Surface Mount, Right Angle) (J17)
Expansion
Connector
*1x USB3.2, 1x USB2.0 and PCIe x1 lane expansion
Signal Terminated to 40 Position
Connector FFC (J9)
USB
2x USB 3.2 / USB 2.0 1x USB3 Dual port RA (J4)
1x USB2.0 1x5 Header (J21)
*1x USB3.2 / USB2.0 2x5 Header (J12)
Serial Ports
1x port that is jumper configurable RS-232/485 in
Standard variant (JAX-BB01 and JAX-BB02). 1x
UART port in Custom variant (9242652).
Signal Terminated to both RJ12
Connector (J1) and 2x5 Header (J7)
1x RS232 through MAX232
Signal Terminated to 2x5 Header
(J7)
Display 1x HDMI 2.0a/b directly from the module with audio
1x Vertically stacked HDMI
connector (J6)
Camera 2x 4 lane CSI-2 Camera Interface 80 pin B2B Connector (J27)
Digital I/O
16x Digital IO 3.3V/5V realized using I2C GPIO
expander
2x10 Header (J10)
CAN 1x CAN interface 1x4 SMD connector (J14)
Fan 1x Fan connector to support active thermal solution 1x4 SMD connector (J15)
Utility
FORCE RECOVERY, PWR_BTN, RESET, I2C, SPI,
DEBUG UART, FORCE OFF
2x10 Header (J13)
Operating System Suppor
t
Linux Kernel version 4.9; Ubuntu 20.04
Mechanical, Electrical and Environmental Propertie
s
Form-Factor 85mm x 110mm
Cooling Mechanism Conduction Cooling
Power Input Range +7 to +20VDC, +12V Typical
Operating Temperature
Range
-25°C to +80°C ambient
RoHS Compliant
*1x Ethernet (from I210) and 1x USB3.2 / USB2.0 (on 2x10 header) will be not supported when expansion cards are used.
