Diesse cube 30 touch - Instrument Technical Specifications

Rev. 2.3
CUBE 30 TOUCH | USER MANUAL
18
The version number is visible on the Service page
2.4 Technical features
USE
Internal use
POWER SUPPLY
Europe: 230Vac@50Hz;
USA/Canada: 110-120Vac@60Hz
Power input: 100VA
DIMENSIONS (mm) 310 x 470 x 403 (l x w x h)
WEIGHT 15 kg
TEMPERATURE
15-35°C (operating)
5-45°C (storage)
RELATIVE HUMIDITY
(RH)
20%-80% without condensation
ALTITUDE up to 2000 meters
NOISE LEVEL below 80 decibels
POLLUTION LEVEL 2 pollution degrees
MEASUREMENT
RANGE
1 - 140 mm/h
1 -90 (for pediatric tube)
CENTRAL UNIT ARM Cortex-M4 180 MHz Microprocessor
DISPLAY 10.1” vertical, wide
OPTICAL UNIT 2 pairs of optical elements
INTERFACES
USB Host; USB Client; 2x RS232
PROTECTION CLASS
I
SAFETY STANDARDS
EN 61010-1:2010; EN 61010-2-081:2015; EN
61010-2-101:2015
EMC
EN 61326-1:2013; EN 61326-2-6:2013
INSTALLATION
CATEGORY
II
PRINTER
Alphanumeric with 57 mm wide thermal paper, 36
characters / line, speed XX mm / sec.
