CUBE 30 TOUCH | USER MANUAL
3.6 Installation procedure
1. Position the instrument on a solid surface, as described above.
Figure 13 - Instrument installation
2. Verify that the power switch is in the “OFF” position.
3. Open the cover, unscrew the central knob, and remove the stabilizing plate used
for transport. Insert the plastic adaptor per (“A” in Figure 9) only when using
"Conventional Closure" type tubes (with low height rubber stoppers) and screw
the central knob back in place to secure the carousel. QC tubes supplied by Diesse
may be run with or without the plastic adaptor.
4. Connect the power supply cable.
5. Optional - Before switching on the instrument, connect the external barcode
reader (accessory).
IN CASE OF FIRE OR GENERAL DANGER, TURN OFF THE INSTRUMENT AND
UNPLUG THE POWER CABLE.
3.7 Disposal
The CUBE 30 TOUCH instrument, to be functional, relies on the use of an electrical power
source and therefore, in compliance with the EUROPEAN DIRECTIVE 2012/19/CE of July
04, 2012 and later amendments by the European parliament, it is classified as Electrical-
Electronic Equipment.
Disposal of the instrument at the end of its life cycle, must be executed in accordance
with local waste disposal regulations.
