Hardware Back panel
Digi Connect EZ Mini User Guide
29
Back panel
Item Name Description
1 Mounting tabs
The mounting tabs on the device are used
to mount the device onto a mounting
surface.
Use round-head M4 size screws. The type
and length are dependent on the
mounting surface type. Screws are not
provided.
If you choose not to mount the device, you
can permanently remove the mounting
tabs with a pliers.
2 Reset button
Use to reset the device to factory defaults.
3 DIN rail clip
You can attach a DINrail clip to the back of
the device and then mount the device to a
DINrail.
