Digi Connect EZ Mini User Manual

Connect equipment to the Connect EZ serial port Serial Status page
Digi Connect EZ Mini User Guide
25
DB-9 pin EIA-232 EIA-422 EIA-485 Half-duplex
2 RxD RxD+ Data+
3 TxD TxD+ Not used (Reserved)
4 DTR RTS- Not used
5 GND GND GND
6 DSR RxD- Data-
7 RTS RTS+ Not used
8 CTS CTS+ Not used
9 RI TxD- Not used (Reserved)
Shell GND
Serial Status page
The Serial Status page contains status information about all of the serial ports available on the
device.
To get to this page, choose Status > Connections > Serial.
Item Description

configuration
icon
Click the  (configuration) icon in the upper right corner of the page to access the
Serial Configuration page. See Serial port for more information.
Status Displays the connection status.
n CONNECTED: A terminal, SSH, TCP, or telnet session is active.
n NOSIGNAL: CTS or DCD is not active on the port.
Port A list of the ports on the device.
The port number and name displays as a link when the port is configured for
remote access. You can click the port number or name to connect to the port in the
terminal page.
1. Click the link to connect to the port in the terminal page.
2. In the terminal screen, enter ~b? to display additional commands. See
Access the terminal screen from the web UI for more information about the
commands.
While you are connected to the terminal, the port status displays in the Status
column as CONNECTED, and the name of the user logged into the device displays in
the User column.
Label A description for the port.
You can change this from the Serial Configuration page. Click the 
(configuration) icon in the upper right corner of the page to access that page.
The port number and name displays as a link when the port is configured for
