Services Modbus gateway

Digi Connect EZ Mini User Guide

410

Resource Shortages : 0

Servers

-------

modbus_socket

-------------

Client Lookup Errors : 0

Incoming Connections : 4

Packet Errors : 0

RX Broadcasts : 0

RX Requests : 12

TX Exceptions : 0

TX Responses : 12

Clients

-------

modbus_socket_41

----------------

Address Translation Errors : 0

Connection Errors : 0

Packet Errors : 0

RX Responses : 4

RX Timeouts : 0

TX Broadcasts : 0

TX Requests : 4

modbus_socket_21

----------------

Address Translation Errors : 0

Connection Errors : 0

Packet Errors : 0

RX Responses : 4

RX Timeouts : 0

TX Broadcasts : 0

TX Requests : 4

modbus_serial_client

--------------------

Address Translation Errors : 0

Connection Errors : 0

Packet Errors : 0

RX Responses : 4

RX Timeouts : 0

TX Broadcasts : 0

TX Requests : 4
