Firewall Configure Quality of Service options
Digi Connect EZ Mini User Guide
591
Command line
1. Select the device in Remote Manager and click Actions > Open Console, or log into the
Connect EZ local command line as a user with full Admin access rights.
Depending on your device configuration, you may be presented with an Access selection
menu. Type admin to access the Admin CLI.
2. At the command line, type config to enter configuration mode:
> config
(config)>
3. Add a binding:
(config)> add firewall qos end
(config firewall qos 2)>
New binding are enabled by default. To disable:
(config firewall qos 2)> enable false
(config firewall qos 2)>
4. (Optional) Set a label for the new binding:
(config firewall qos 2)> label my_binding
(config firewall qos 2)>
5. Set the interface to queue egress packets on. The binding will only match traffic that is being
sent out on this interface:
a. Use the ? to determine available interfaces:
b. Set the interface. For example:
(config firewall qos 2)> interface /network/interface/eth1
(config firewall qos 2)>
6. (Optional) Set the maximum egress bandwidth of the interface, in megabits, allocated to this
binding.
(config firewall qos 2)> bandwidth int
(config firewall qos 2)>
where int is an integer between 1 and 1000. Typically, this should be 95% of the available
bandwidth. The default is 95.
7. Create a policy for the binding:
At least one policy is required for each binding. Each policy can contain up to 30 rules.
a. Change to the policy node of the configuration:
(config firewall qos 2)> policy
(config firewall qos 2 policy)>
