DWG2000E/F/G GSM/CDMA VoIP Gateway User Manual
_______________________________________________________________________________
Shenzhen Dinstar Technologies Co., Ltd.
20
Canceded: the call was canceled by calling party
No Carrier: the call was rejected by mobile network
Not Answered: no body to answer the call
Busy: user busy
Durations
Call duration of the call
RTP send/recv/loss rate
RTP Statistics of the call
4.4.6 Auto Lock BCCH History
Figure 4-4-6 Auto Lock BCCH History
It is record history of BCCH to help analysis SIM card register status.
4.5 Network Configuration
4.5.1 Local Network
Figure 4-5-1 Local Network
Table 4-5-1 Local network
Parameters
Description
