DWG2000E/F/G GSM/CDMA VoIP Gateway User Manual
_______________________________________________________________________________
Shenzhen Dinstar Technologies Co., Ltd.
24
API Server Port
To define communicate port between gateway and API server. This is an
option when selecting "Yes" under "remote API enable"
API User
ID/Password
To define authentication user name and password between gateway and
API server.
Transmitted
Power
Transmit power of module. Use the default setting value and contact with
technical support if need to change it.
USSD Defaulting
Encoding
Encoding of USSD, default is UCS2.
Voice Quality
Keep the parameter as default except the device is facing low ASR issue.
To adjust voice quality level possibly help to improve low ASR issue but
may affect voice quality.
Abnormal Call
handle
It is an optional parameter to handle abnormal calls.
Notes: please reference API document for more details.
Example:
Configuration between SMS box and gateway
Configure API parameters on gateway
The IP server which installed SMS box software is 172.16.221.221, pre-set Port 12000,
User ID aabbcc and password abc123 as example.
Configure SMS box
(Next Page)
