73ECL-PTU-207 Preloaded Applications
TYPE
This menu is used to select the type of system (2 pipes, 4 pipes, etc.)
Parameter Default Valid
Choices
Description
TYPE
(EC6)
0 CL 2 Pipes cooling
1 CL-EH 2 Pipes cooling with electric heater
2 HT 2 Pipes Heating
3 HT-EH 2 Pipes Heating with electric heater
4 CO 2 Pipes Change Over
5 CO-EH 2 Pipes Change Over with electric heater
X 6 CL-HT 4 Pipes
7 CL-HT-EH 4 Pipes with electric heater
FAN
This menu is used to configure the fan type.
Parameter Default Valid
Choices
Description
FT
(nviFP39)
0 NONE Fan control is not used
1 1 SP 1-Speed fan
2 2 SP 2-speed fan
3 3 SP 3-speed fan
X 4 ECM ECM motor (0-10V output)
Table9: Fan Ctrl Type
Allure EC-Smart-Vue Screen-by-Screen Guide
