XF6 Series Installation and Programming Guide Digital Monitoring Products
15
715-16 Zone Expander Provides 16 powered zones (12VDC) supporting two-wire smoke detectors or
other fire alarm initiating devices. Includes red 340 enclosure and EOL resistors.
716Output Expander Provides 4 programmable Form C (SPDT) relays and four open collector
annunciator outputs. Use the outputs for remote zone and system annunciation or
environmental control applications. Harness included.
Auxiliary Modules
860Relay Output Module Provides electrical isolation between the alarm panel and other systems or for
switching voltage to control various functions.
865 Class A/B Notification
Module
Provides Class A or B supervision for ground faults, opens, and shorts on
notification appliance circuits.
866 Class B Notification Module Provides one 5 Amp Class B notification circuit for supervising listed, polarized
notification devices such as bells, strobes, and horns.
867 Class B LX-Bus Notification
Circuit Module
Provides one supervised Class B circuit for 12 VDCor 28VDC notification devices.
The 867connects to the LX-Bus and supervises Ground Fault, Open and Short
conditions on the notification circuit.
Pull Stations
850Series Pull Stations Single or dual action pull stations with gold-plated SPST contacts and terminal
strip connections.
Smoke/Heat Detectors
2W-BLX Conventional Smoke
Detector
A photoelectric detector that includes an addressable single point module for
connection to the LX-Bus of the XF6 Series panels.
2WT-BLX Conventional Smoke/
Heat Detector
A photoelectric detector that includes an addressable single point module with a
restorable, built-in fixed temperature thermal detector and is capable of sensing a
temperature higher than 135 °F.
Miscellaneous Accessories
335Intrusion Siren Oers dual tones, steady and warble, is load-tested to four hours, is indoor surface-
mounted and is made out of UV-resistant, high-impact ABS plastic. 105dB.
370Lightning Suppressor Provides lightning supression for any DMP or other manufacturer’s panel.
861Power Distribution Module Provides multiple auxiliary power terminals and additional keypad and/or LX-Bus
connectors for a clean installation. Maximum current handling capacity of 8amps
on power and ground in terminals.
Wiring harnesses, cables, and
tampers
300Four-wire Harness
303Silence/Reset Push Button
305Plug-in Output Relay
306Tamper Harness
307-S Screw-On Tamper Switch
374Surge Voltage Suppressor
3012Clip-On Tamper Switch
381Coax Extension Cable
431Output Harness
Monitoring Center Receivers
SCS-1R Network Enabled
Receiver
Network Enabled Receiver compatible with central station receivers that accept
Standard CID, DD or DMP Serial 3messaging.
SCS-VR Virtual Receiver Software-only solution that runs on a server for network IP and cellular
communications.
DMP Wireless
1100X Receiver Provides Two-Way, supervised communication using 900MHz frequency hopping-
spread spectrum technology. 1100XE-W features 128-bit AES encryption.
1100XH High-Power Receiver Provides additional transmit and receive amplification for improved performance at
greater distance or harsh building environments. 1100XHE-W features 128-bit AES
encryption.
1100R Repeater Provides increased communication range. Up to eight repeaters can be installed on
a wireless system. This model includes the 376L power supply. 1100RE-W features
128-bit AES encryption.
1103Universal Transmitter,
External Contact
Includes an internal magnetic reed switch, an on board terminal block for external
contact wiring, and an end-of-line resistor. Features 128-bit AES encryption.
