Product Introduction
Overview
Figure 3.1 Robot overview
The main components of the robot system include:
⚫ CR robot: six-axis robot arm, main moving parts.
⚫ Controller: core computing and electrical components.
⚫ Emergency stop switch: connected to the controller to realize the emergency stop
function.
⚫ Wireless receiver: plugged into the controller, so that the operating terminal can be
connected to and control the robot via WiFi.
⚫ Heavy-duty cable: connect the robot arm to the controller.
In addition, the system includes an operating terminal (tablet or PC) for installing the robot
control software.
