DSE Model 5510 Autostart Control and Instrumentation System Operators Manual
057-015 5510 OPERATING MANUAL ISSUE 11 07/07/09 AM 24
OIL PRESSURE SENDER OPEN CIRCUIT, if the module detects a loss of signal from the oil
pressure sender (open circuit) a shutdown is initiated. Alarm Shutdown Sender Fault will be
displayed. Sender failure is not delayed, it is an immediate shutdown.
Alarm
Shutdown
Oil press sender fault
MAGNETIC PICKUP OPEN CIRCUIT, if the module detects a problem with the connection to the
magnetic pickup (open circuit) a shutdown is initiated. MPU failure is not delayed, it is an immediate
shutdown.
Alarm
Shutdown
MPU open circuit
AUXILIARY INPUTS, if an auxiliary input has been configured as a shutdown the appropriate
message will be displayed as configured by the user.
Alarm
Shutdown
Bearing temp high
LOSS OF SPEED SIGNAL, if the speed sensing signal is lost during cranking, a shutdown is
initiated. Alarm Shutdown Loss of Speed Signal will be displayed.
Alarm
Shutdown
Loss of speed signal
NOTE:- This will only occur if the magnetic pickup speed sensing signal is lost during
cranking or during the safety on timer. If the signal is lost during normal operation the
Generator will shutdown with an Under-speed alarm.
CAN DATA FAIL, If the module is configured for CANbus operation and does not detect
data on the engine CANbus datalink, a shutdown will occur and ‘Can data fail’ is shown on
the module’s display.
Alarm
Shutdown
Can data fail
