CAN ECU FAIL, If the module is configured for CANbus operation and receives a “fail”
message from the engine control unit, the engine is shutdown and ‘Can ECU fail” is shown
on the module’s display.
Example
Alarm
The display will alternate
between the text display
and the manufacturers
error codes
Alarm
Can ECU fail
Fuel pressure low
Can ECU fail
SPNnnnnnnn
FMInnnnnnn
NOTE: - If the CAN message is a manufacturers specific code, it may not be
displayed as text. If this is the case, the display will show the generic manufacturers code
only, which must be cross-referenced with the engine manufacturer’s literature. Please
contact the engine manufacturer for further assistance.
The above displays show a standard J1939 based system. Other manufacturers systems
supported by the module work in a similar way though the exact detail may vary from
those illustrated.
Example
Alarm
Can ECU fail
SPNnnnnn
FMInnnn
GENERATOR EARTH FAULT, if the module detects a generator earth fault current in excess of the
pre-set trip a shutdown is initiated. The LCD will indicate ‘EARTH FAULT’. This alarm is
configurable between Warning, Shutdown and Electrical Trip. “Shutdown” is the factory default
setting.
Alarm
Shutdown
Earth Fault
AIR FLAP CLOSED, if the module detects feedback to indicate that the engine air intake flap is
closed a shutdown alarm will be initiated.
Alarm
Shutdown
Air flap closed
NEGATIVE PHASE SEQUENCE, if the module detects an imbalance in the load current of each
phase above a pre-set level, then the following warning will occur.
Alarm
Shutdown
Negative phase Sequence
