MSC OLD UNITS ON BUS, if the module detects a module on the MSC link which is incompatible
with the current module, then the MSC Compatibility alarm will be triggered. Check the configuration
(using 5xxx configuration software) to ensure correct MSC mode is selected (Extended functionality
/ Pre version 6 compatibility) Incompatible modules without configurable MSC mode will need to be
replaced with compatible units.
Alarm
MSC old units on bus
MSC ID ERROR, all modules on the MSC link must have an unique ID number. On later modules,
ID’s are automatically assigned when joining the MSC link. On modules prior to version 5.00, the ID
must be set using 5xxx configuration software.
Alarm
MSC ID Error
MSC FAILURE if the module is unable to detect the MSC link then the MSC Failure alarm will be
triggered. Incorrect wiring type or connection may be a possibility.
Alarm
MSC Failure
LOSS OF EXCITATION, the module will monitor the KVAr present on the generator. Should this
exceed a pre-set amount of negative VAr this indicates a possible loss of excitation on the
alternator. The following alarm will then be generated.
Alarm
Warning
Loss of Excitation
kW OVERLOAD ALARM
The kW level provided by the set is above the level of the kW Overload shutdown alarm.
Alarm
Shutdown
kW Overload Alarm
ENGINE INLET TEMPERATURE
The engine inlet temperature (electronic engines only) is above the level of the Engine Inlet
Temperature shutdown alarm.
Alarm
Shutdown
Engine Inlet Temperature
