Specifications DTG M Series Maintenance Manual
2.3 Part Names and Functions
Part names and functions are explained in this section.
For the directions described in this document, refer to the following orientation figure:
Left
Upper
Rear
Front
Right
Lower
FIGURE 2-1 PRINTER ORIENTATION
