DTG M Series Maintenance Manual
iii
III. About this Manua l
A. Purpose and Target Readers
This manual explains the preparations and procedures for operating the DTG M series printer.
This is a common User Guide for the DTG M series of printers. Unless specifically mentioned to the
contrary, the descriptions in this manual are common for all DTG M series models.
This manual is designed to assist the end user in the use, maintenance and general troubleshooting
of the DTG M series printers. Before using the DTG M series printer you are required to read and
fully understand the contents and directions in this manual.
B. Manual Configuration
Section
Contents
1 Safety Instructions
Explains types of warnings, cautions and warnings labeled on the
printer
for both the operators of the printer and maintenance personnel.
2 Product Overview
Explains the features, part names, and functions of the printer.
3 Specifications
Explains the specifications of the printer.
4 Parts Replacement
Explains the procedures of replacement and removal of the
service parts
of the printer.
5 Self-Diagnostic Mode
Explains the self-diagnostic functions of the printer.
6 Maintenance Mode2
Explains the maintenance mode2 of the printer.
7 Adjustment
Explains the adjusting procedures of the printer parts.
8 Maintenance
Explains daily maintenance of the printer.
9 Troubleshooting
Explains troubles that may occur when using the printer and
how to
solve them.
10 Appendix
Explains the maintenance information and the exploded views
for this
printer.
