23
DTG M Series Maintenance Manual Initial Setup & Basic Operations
Left
Upper
Rear
Front
Right
Lower
FIGURE 3-2 PRINTER FRONT
SECTION PARTS
FIGURE 3-1 PRINTER ORIENTATION
Top Cover (Lid)
Emergency stop
LCD and keypad
Bed
up/down
status
light
Bed Load/eject
buttons &
status light
Waste ink
access
Pressure reset
and status light
Bulk ink
system
Media
tray
