Check engine oil level
Check the engine oil level through the sight glass (1)
on the clutch cover.
Oil level should be between the marks on the sight
glass. If the level is low, top up with engine oil.
Ducati prescribes the only use of SAE 15W-50/JASO
MA2 oil and recommends the use of Shell Advance
DUCATI 15W-50 Fully Synthetic Oil.
Remove the oil filler plug (2) and top up until the oil
reaches the required level. Refit the plug.
UK VERSION: Ducati recommends you use
Shell Advance DUCATI 15W-50 Fully Synthetic Oil.
Engine oil and oil filters must be changed by a
Ducati Dealer or Authorised Service Centre at the
intervals specified in the scheduled maintenance
contained in this manual in the sub-section
“Scheduled maintenance”.
To check the oil level correctly, carefully follow the
instructions below.
1) The level should be checked at warm engine, about
15 minutes the engine has been stopped.
2) Position the bike with both wheels on a flat ground
and in straight position.
3) Then, check the engine oil through the sight glass.
4) If the oil level is below the middle line between the
MIN and MAX marks, add oil until reaching the
maximum level indication.
Never exceed the MAX mark.
Recommendations concerning oil
It is recommended to use oil complying with the
following specifications:
Fig 262
290
