Tank filler plug
Opening
flap (1) and the key in the lock.
Turn the key clockwise to release the lock.
the plug (2).
Closing
Turn the key in the plug clockwise to release the lock.
Close the plug (2) with the key and push it
down into its seat until you hear its locking "click”.
Remove the key and close flap (1) protecting the lock.
Note
Plug can only be closed when key is
refuelling, always make sure that the plug
is in place and closed.
Fig 6
Fig 7
35
