Holding it by the handle (2), pull the side bag (6) out
of the housings (5) in hooks (4), first pulling out the
rear and then the front, and from the lower
(7).
Repeat the same operation for removing the other
side bag.
To fit/remove the subframe kit for aluminium
side panniers and to set it to “floating” or “fixed”
mode, please contact your Ducati Dealer or
authorised service centre.
Fig 36
Fig 37
55
