2-21
Chapter 2 Basic Operation
2
Adjust the position of the stopper of the
reject tray in accordance with the paper
size.
Follow this procedure only when using LUL-
HM.
2-8. Position of Stack Height Sensor
Make sure not to insert your hands inside the paper feed bin while the suction belt or convey-
ance shaft is driving.
Otherwise injuries may occur.
1
Rotate the stack height sensor adjust-
ment to adjust the position of the stack
height sensor.
• Set to "1.5" under normal conditions
• When miss feed occurs frequently in the
middle of collation, rotate to the lower ar-
row's direction. When double-feed (which
means that more than two sheets of paper
are fed at once) occurs frequently, rotate to
the upper arrow's direction.
(For North America)
(For North America,EU)
(For North America)
(For North America,EU)
To Next Page
