1. Specifications
Model DSC-10/20
Type Floor-type
The number of bins 10 / tower
Maximum number of
units connectable
2
Feeding system Belt suction feed system by fan motor
Conveyance system Conveyance roller + at belt method
Maximum paper loading
height
35 mm/1.38 inches (400 sheets of ne quality paper 64 g/m
2
)
Maximum paper loading
height (stacker)
100 mm/3.94 inches
Paper size Minimum width: 139.7 mm / 5.50 inches, Maximum width: 320 mm / 12.60 inches
Minimum length: 210 mm / 8.27 inches, Maximum length: 450 mm / 17.72 inches
Paper weight Fine quality paper: 52.3 to 250 g/m
2
Art/coated paper: 79.1 to 210 g/m
2
*Fine quality paper 250 g/m
2
may not be able to be fed depending on the usage environment.
*Several restrictions are applied to paper exceeding 157g/m
2
.
Paper type Sheet
Processing speed Maximum 7200 sets/hour (diers according to the downstream unit)
Error detection Double-feed, miss feed, paper jam
Other detection
functions
No paper, conveyance board open/close, exterior cover attached/removed,
communication error, paper jam at conveyance bridge
Error display Collectively displayed on control panel
Paper feed error, conveyance cover open/close, paper receiving table full, downstream
unit error, no paper in bin, double-feed, miss-feed, paper jam
Counter Numerical key input, Count up display, Count down display
Additional functions Preset / Alternate Mode / Block Mode (1/2, 1/4) / Interleaf insert Mode /
Paper eject direction (left or right) / Paper reject / Waiting Mode /
Manual paper feed (when using LUL-HM, up to 10 sheets) /
Reject function (when using LUL-HM)
Dimensions • DSC-10/20+LUL-HM
1345 mm / 53 inches (W) x 780 mm / 30.7 inches (D) x 1708 mm / 67.3 inches(H)
• DSC-10/20+DSC-10/20 STACKER
770 mm / 30.4 inches (W) x 780 mm / 30.7 inches (D) x 1708 mm / 67.3 inches(H)
• DSC-10/20 x 2+DSC-10/20 BRIDGE+LUL-HM
2185 mm / 86.1 inches (W) x 780 mm / 30.7 inches (D) x 1708 mm / 67.3 inches(H)
• DSC-10/20 x 2+DSC-10/20 BRIDGE+DSC-10/20 STACKER
1610 mm / 63.4 inches (W) x 780 mm / 30.7 inches (D) x 1708 mm / 67.3 inches(H)
Airborne noise • Single tower with LUL-HM, left side ejection
Equivalent continuous A-weighted sound pressure level: 72 dB,
Sound pressure level:96 dB (including the peak)
• Single tower with stacker, right side ejection, high speed
Equivalent continuous A-weighted sound pressure level: 71 dB,
Sound pressure level:92 dB (including the peak)
• Measurement condition:
Using A3/LD ne quality paper (81.4 g/m
2
), feeding from all bins, process speed 4000 sets/h.
Horizontal position: 1 m/39.4 inches from the control panel
Vertical position: 1.5 m/59.01 inches from oor surface
Power supply AC 120 V 60 Hz (North America)AC 220 to 240 V 50/60 Hz (EU)
Power consumed 8.1 A , 890 W (North America)4.2 A , 860 W (EU) (One tower)
Weight 227.5 kg / 501.6 lb (One tower)
Specications and dimensions are subject to change without prior notice for improvements

Duplo DSC-10/20 Specifications

General

Brand	Duplo
Model	DSC-10/20
Category	Printer
Language	English
