3-1
Chapter 3 Advanced Operation
Chapter 3 Advanced Operation
1. Manual Paper Feed
Paper can be fed manually using the optional LUL-HM.
Up to ten sheets can be fed at the same time. Manual paper feed is available only for left side ejection.
1-1. Using the Downstream Unit
Load paper to the downstream unit manually.
1
Select the OPTIONS menu.
2
Select the LUL-HM menu.
If LUL-HM is not connected, the LUL-HM menu
will not be displayed.
3
Touch DN Unit Handfeed Set to set to
“ON”. The downstream unit starts to run
and stands by for receiving paper.
4
Adjust the paper guide of the hand mar-
ry in accordance with the paper size.
5
Set the auxiliary plates in accordance
with the paper size as shown in the fig-
ure.
To Next Page
