The absolute pressure is assigned and the program returns to
menu 3.3MX1.1.4.
Once all sources have been assigned in this manner, return to
the measurement display by pressing the
key.
The display
may then look similar to that displayed in Fig.15.63,
depending on the selection of the composition.
Note:
In order to view all four measured values simultaneously, the
display may also need to be set to output four measured values.
See also: 15.9.2 Example: Selection Number of the displayed
measurement channels [}171]).
15.15 Example: Configuring external sensor software
module
Besides the DURAG sensors, additional sensors need to be con-
nected to a measuring system, which only have an analogue in-
terface (4 … 20mA). However, the Measurement display for
these sensors will not output the current value, but rather the
(converted) measurement variable with the desired unit (°C, hPa,
m/s, Nm³/h, etc.).
The External sensor software module can assign
analogue sig-
nals of a measured variable. The D‑ISC100 converts the current
value to the desired unit. The relevant values can then be dis-
played and evaluated.
Requirement:
● At least one analogue input expansion module (available as
an option) is installed.
Four analogue input channels are available per module; i.e.
four sensors can be connected per channel, or fewer sensors
with multiple channels can be connected to the analogue in-
put module.
● At least one free analogue input channel must be available
and
configured for every connected external sensor.
● The External sensor module must be enabled (see Section
10.4.1.3 Enable/disable modules [}116]).
